A black and white line drawing showing the side elevation of a cantilever sliding gate with dimensions 50 mm and 6200 mm.

Cantilever Sliding Gate – Technical Line Drawing Specification ✅ View • Side elevation (profile) of a single cantilever sliding gate in the closed position • Flat ground shown as a solid baseline ⸻ 📏 Gate Dimensions • Clear opening (span): 6200 mm • Gate height (top of upper rail to underside of bottom rail): 1420 mm • Ground clearance: 80 mm between the bottom of the gate and ground • Total visible gate height from ground to top rail: 1500 mm ⸻ 🧱 Structure • Vertical support post (left side): • Square hollow section (e.g. 80×80 mm) • Base of this post must be aligned with ground level (not below it) • Positioned flush with the gate’s vertical end • Gate frame: • Top rail: straight horizontal beam, aligned with support post • Bottom rail: straight horizontal beam, 80 mm above ground • Vertical bars within the frame, arranged in diagonal cross-brace or “field gate” style • Cantilever tail section (extends beyond the right-hand post): • Housed on a guide track or rollers • Includes a motor box or drive unit on the ground near the tail ⸻ ⚙️ Components to Show • Motor/drive unit: located at the base of the right-hand post, sitting on ground level • Flashing light (optional): on top of the post or gate frame (optional detail) • Roller supports or guide posts under the cantilever tail • Posts on both ends rest on the same ground line ⸻ ✏️ Style Notes • Black and white line drawing • Clean, minimal shading • Add labeled dimensions where possible: • 6200 mm clear opening • 1500 mm See more
