A technical sketch of a kitchen island with a sink, stove, cabinets, and three bar stools. Dimensions are marked in centimeters, showing top and front views.

A technical sketch of a kitchen island with a sink, stove, cabinets, and three bar stools. Dimensions are marked in centimeters, showing top and front views.
Pro

זוהי סקיצה עם מידות מפתח, וחשוב שתעביר אותה לנגר מקצועי לצורך תכנון מפורט, הנדסי וביצוע סופי, כולל בחירת חומרים, פרזול וחלוקת מגירות מדויקת. 📐 תוכנית אי למטבח (מבט על וחזית) האי מתוכנן במידות: אורך 200 ס"מ (2 מטר) ורוחב 120 ס"מ (1.2 מטר). גובה סטנדרטי מומלץ לאי עבודה/ישיבה הוא כ-90 ס"מ. 1. מבט על (חתך עליון) | אלמנט | מידות | הערות | |---|---|---| | אורך כולל | 200 ס"מ | | | רוחב כולל | 120 ס"מ | | | צד אחסון (מגירות) | עומק \approx 60-70 ס"מ | יכלול את יחידות האחסון (מגירות), ימוקם בצד אחד לאורך כל 200 ס"מ. | | צד ישיבה (מגרעת) | עומק \approx 30-40 ס"מ | משטח עבודה בולט מעבר לארונות המגירות, ליצירת מרווח לרגליים. | | מגרעת ישיבה (בעומק 30 ס"מ) | 30 ס"מ | המגרעת ממוקמת בצד הצר (120 ס"מ) לישיבה, ומאפשרת מקום לברכיים. | סידור רוחב השולחן (120 ס"מ): * צד א' (הצד הארוך): יחידת המגירות (למשל, עומק 60 ס"מ) + הבלטת משטח (למשל, 10 ס"מ) = סה"כ כ-70 ס"מ. * צד ב' (הצד המקביל, המיועד לישיבה): המשך יחידת המגירות (שם אין מגירות, יש רק מסגרת/גב) עם מגרעת בעומק 30 ס"מ בקו התחתון, כך שסה"כ הרוחב הוא 70 ס"מ + מרווח לרגליים + עוד בסיס מבני = סה"כ 120 ס"מ. סידור אורך השולחן (200 ס"מ): * צד אחד לאורך כל 200 ס"מ: יהיה מורכב מיחידות מגירות כמו בתמונה ששלחת. * הצד המקביל (לאורך כל 200 ס"מ): יהיה חלק וסגור (גב האי), ללא מגירות, ובגובה המתאים (כ-90 ס"מ). שינוי הנדרש עבור ישיבה של 4 כסאות: כדי לאפשר ישיבה של 4 כסאות, יש למקם את המגרעת לישיבה בצד הצר של 120 ס"מ כפי שציינת: * צד רחב (200 ס"מ): צד אחסון מגירות מול צד סגור (גב האי). * צד צר (120 ס"מ) - צד ישיבה: המשך משטח האי עם מגרעת בעומק 30 ס"מ. * See more
