An isometric pixel art illustration of a busy airport with several airplanes, terminals, ground vehicles, and surrounding roads with trees.

Here’s a pixel grid layout for your 24 in × 55 in airport at **1:400 scale**, using **96 pixels per inch**. This layout accommodates: - **1 Polar 747-8F** - **1 767-300F** - **1 A350-1000** - **1 A321neo** - **1 CRJ-900** --- ### 🧮 Canvas Dimensions - **Width**: 24 in × 96 = **2304 px** - **Length**: 55 in × 96 = **5280 px** --- ### ✈️ Aircraft Dimensions (approximate) | Aircraft | Length (px) | Wingspan (px) | |--------------|-------------|---------------| | 747-8F | 720 px | 640 px | | 767-300F | 518 px | 470 px | | A350-1000 | 697 px | 640 px | | A321neo | 420 px | 460 px | | CRJ-900 | 343 px | 260 px | --- ### 🧭 Layout Zones (suggested pixel positions) #### **Cargo Apron (Left Side)** - **747-8F**: Parked diagonally at (x: 200–920, y: 400–1040) - **767-300F**: Parked nose-in at (x: 1000–1518, y: 400–870) - **Cargo warehouse**: Behind aircraft at (x: 200–1518, y: 100–300) #### **Passenger Terminal (Right Side)** - **A350-1000**: Gate 1 at (x: 200–897, y: 3000–3640) - **A321neo**: Gate 2 at (x: 950–1370, y: 3000–3420) - **CRJ-900**: Gate 3 at (x: 1450–1793, y: 3000–3343) - **Terminal building**: Behind gates at (x: 200–1793, y: 2700–2950) #### **Taxiway Loop** - Width: ~300 px - Path: Curves from cargo apron to passenger gates, looping around the center (x: 200–2000, y: 1200–2500) #### **Runway (Diagonal or Bottom Edge)** - Width: 432 px - Placement: Diagonal from bottom-left (x: 0, y: 5000) to top-right (x: 2304, y: 4000) --- ### 🧩 Pixel Grid Tips - Use a 96 px grid See more
